SC Standard Cylinder Accessory
Product Details
Overall Dimens
Dimension Sheet
Symbol/Bore(mm) |
32 |
40 |
50 |
63 |
80 |
100 |
125 |
AA |
153 |
169 |
173 |
184 |
200 |
210 |
250 |
AC |
134 |
140 |
149 |
158 |
168 |
174 |
214 |
AD |
9.5 |
14.5 |
12 |
13 |
16 |
18 |
18 |
AE |
50 |
57 |
68 |
80 |
97 |
112 |
140 |
AF |
33 |
36 |
47 |
56 |
70 |
84 |
90 |
AG |
20.5 |
23.5 |
28 |
31 |
30 |
30 |
45 |
AH |
28 |
30 |
36.5 |
41 |
49 |
57 |
90 |
AP |
9 |
12 |
12 |
12 |
14 |
14 |
16 |
AT |
3.2 |
3.2 |
3.2 |
3.2 |
4 |
4 |
6 |
Overall Dimens
Dimension Sheet
Symbol/Bore(mm) |
32 |
40 |
50 |
63 |
80 |
100 |
125 |
BA |
28.3 |
32.3 |
38.3 |
38.3 |
47.3 |
47.3 |
56 |
BB |
10 |
10 |
10 |
12 |
16 |
16 |
20 |
BC |
47 |
52 |
65 |
76 |
95 |
115 |
140 |
BD |
33 |
36 |
47 |
56 |
70 |
84 |
90 |
BE |
72 |
84 |
104 |
116 |
143 |
162 |
224 |
BF |
58 |
70 |
86 |
98 |
119 |
138 |
180 |
BH |
6.5 |
6.5 |
6.5 |
8.5 |
10.5 |
10.5 |
15 |
AJ |
10.5 |
10.5 |
10.5 |
13.5 |
16.5 |
16.5 |
19 |
AK |
6.5 |
6.5 |
6.5 |
8.5 |
10.5 |
10.5 |
12.5 |
BP |
7 |
7 |
9 |
9 |
11 |
11 |
16 |
T |
33 |
|
47 |
56 |
70 |
84 |
110 |
Overall Dimens
Dimension Sheet
Symbol/Bore(mm) |
32 |
40 |
50 |
63 |
80 |
100 |
125 |
S |
44 |
50 |
62 |
75 |
94 |
112 |
140 |
T |
33 |
37 |
47 |
56 |
70 |
84 |
110 |
DC |
34 |
34 |
34 |
34 |
48 |
48 |
50 |
DD |
13 |
14 |
15 |
15 |
20 |
20 |
25 |
DE |
12 |
14 |
14 |
14 |
20 |
20 |
25 |
DJ |
13 |
14 |
15 |
15 |
20 |
20 |
25 |
DQ |
16 |
20 |
20 |
20 |
32 |
32 |
70 |
DH |
10 |
10 |
10 |
10 |
15 |
15 |
15 |
D |
6.5 |
6.5 |
6.5 |
8.5 |
10.5 |
10.5 |
12.5 |
Overall Dimens
Dimension Sheet
Symbol/Bore(mm) |
32 |
40 |
50 |
63 |
80 |
100 |
125 |
S |
48 |
50 |
62 |
75 |
94 |
112 |
140 |
T |
33 |
37 |
47 |
56 |
70 |
84 |
110 |
CC |
19 |
19 |
19 |
19 |
32 |
32 |
50 |
CD |
5 |
5 |
3 |
3 |
8 |
8 |
25 |
CE |
12 |
14 |
14 |
14 |
20 |
20 |
25 |
CJ |
13 |
13 |
15 |
15 |
21 |
21 |
25 |
CP |
16.3 |
20.5 |
20.3 |
20.3 |
32.3 |
32.3 |
70 |
CT |
32 |
44 |
52 |
52 |
64 |
64 |
120 |
PA1 |
41 |
51.8 |
60.3 |
60.3 |
73.8 |
73.8 |
130 |
PB1 |
33.5 |
45.8 |
54 |
54 |
65.5 |
65.5 |
121.5 |
CH |
10 |
10 |
10 |
10 |
15 |
15 |
15 |
D |
6.5 |
6.5 |
6.5 |
8.5 |
10.5 |
10.5 |
12.5 |
Overall Dimension
Symbol/Bore(mm) | EB | EC | ED | EE | EP | ET | HA | HB | HC | HD | HE | HF | HI | HJ | HP | HQ | HT |
40 | 113 | 63 | 37 | 80 | 45.5 | 22 | 109 | 86 | 81.5 | 50 | 12 | 23 | 12 | ||||
50 | 126 | 76 | 47 | 76 | 25 | 30 | 110 | 80 | 55.5 | 22 | 122 | 99 | 88 | 50 | 12 | 23 | 12 |
63 | 138 | 88 | 56 | 88 | 25 | 30 | 110 | 80 | 68.5 | 22 | 134 | 111 | 94 | 50 | 12 | 23 | 12 |
80 | 164 | 114 | 70 | 114 | 25 | 35 | 110 | 80 | 87.5 | 22 | 160 | 137 | 127 | 70 | 14 | 23 | 14 |
100 | 182 | 132 | 84 | 132 | 25 | 40 | 110 | 80 | 107.5 | 22 | 178 | 155 | 136 | 70 | 14 | 23 | 14 |
125 | 209 | 154 | 110 | 158 | 30 | 36 | 145 | 105 | - | - | 212 | 185 | - | 85 | 18 | 27 | 28 |
Overall Dimension
Symbol/Bore(mm) | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 |
NA | 12 | 16 | 20 | 19 | 25.4 | 32 | 32 | 44.4 | 44.4 | 62 |
NB | 6 | 8 | 10 | 20 | 24 | 32 | 32 | 40 | 40 | 49 |
NC | 6 | 8 | 10 | - | 12 | 16 | 16 | 20 | 20 | 20 |
ND | 24 | 32 | 40 | 40 | 48 | 64 | 64 | 80 | 80 | 100 |
NE | 30 | 40 | 52 | - | 67 | 89 | 89 | 112 | 112 | 120 |
NF | 8.5 | 11 | 15 | 15 | 24 | 32 | 32 | 40 | 40 | 1 |
NG | 10 | 15 | 20 | 20 | 20 | 23 | 23 | 30 | 30 | 55 |
NH | M6 | M8 | M 10x1.25 | M10x1.25 | M 12x1.25 | M16x1.5 | M16x1.5 | M20x1.5 | M20x1.5 | M27x2 |
NJ | 6 | 10 | 14 | - | 20 | 22 | 22 | 30 | 30 | - |
NK | 11.5 | 14 | 18 | 18 | 23 | 30 | 30 | 39 | 39 | 38 |
NM | 6 | 8 | 11 | - | 12 | 16 | 16 | 20 | 20 | 32.5 |
NP | 10 | 17 | 21 | 20 | 24 | 32 | 32 | 40 | 40 | 40 |
NQ | 30 | 40 | 51 | - | 62 | 83 | 83 | 105 | 105 | 120 |
PA | 17 | 19 | 25 | 25 | 32.8 | 39.3 | 39.3 | 53.3 | 53.3 | 74 |
PB | 12 | 16 | 20 | 19.5 | 26.5 | 33 | 33 | 45 | 45 | 64 |
Overall Dimensio
Dimension Sheet
Symbol/Bore(mm) | MA | MB | MC | MD | ME | MF | MG | MH | Ml | MJ | MK |
20 | 51 | 20 | 6 | - | 8 | M8 | 12 | 24 | 13 | 8 | M8 |
25 | 58 | 22 | 7 | 21 | 8 | M10x1.25 | 12 | 26 | 17 | 10 | M10x1.25 |
32 | 58 | 22 | 7 | 21 | 8 | M10x1.25 | 12 | 26 | 17 | 10 | M10x1.25 |
40 | 58 | 22 | 8 | 21 | 7 | M12x1.25 | 12 | 28 | 19 | 12 | M12x1.25 |
50 | 90 | 27 | 10 | 41 | 12 | M16x1.5 | 14 | 45 | 27 | 15 | M16x1.5 |
63 | 90 | 27 | 10 | 41 | 12 | M16x1.5 | 14 | 45 | 27 | 15 | M16x1.5 |
80 | 102 | 29 | 13 | 46 | 14 | M20x1.5 | 18 | 53 | 33 | 22 | M20x1.5 |
100 | 102 | 29 | 13 | 46 | 14 | M20x1.5 | 18 | 53 | 33 | 22 | M20x1.5 |
Overall Dimension
Symbol/Bore(mm) | PA | PB | PC | PD | PE | PF | PG | PH | PI | PJ | PK | PL | PM |
20 | 8 | 12 | 9 | 10.4 | 22 | 36 | 47 | M8 | 17 | 16 | 12.5 | 5 | 14 |
25 | 10 | 14 | 11 | 12.9 | 26 | 43 | 56 | M10x1.25 | 21 | 19 | 15 | 6.5 | 17 |
32 | 10 | 14 | 11 | 12.9 | 26 | 43 | 56 | M10x1.25 | 21 | 19 | 15 | 6.5 | 17 |
40 | 12 | 16 | 12 | 15.4 | 30 | 50 | 65 | M12x1.25 | 24 | 22 | 17.5 | 6.5 | 19 |
50 | 16 | 21 | 15 | 19.3 | 38 | 64 | 83 | M16x1.5 | 33 | 27 | 22 | 8 | 22 |
63 | 16 | 21 | 15 | 19.3 | 38 | 64 | 83 | M16x1.5 | 33 | 27 | 22 | 8 | 22 |
80 | 20 | 25 | 18 | 24.3 | 46 | 77 | 100 | M20x1.5 | 40 | 34 | 27.5 | 10 | 32 |
100 | 20 | 25 | 18 | 24.3 | 46 | 77 | 100 | M20x1.5 | 40 | 34 | 27.5 | 10 | 32 |
